Product Details:
|
| Product Name: | Din 1.2311, Steel Round Bar Plastic Mould Steel, P20/3Cr2Mo/1.233 Pre Hardened Plastic Mould Steel Plate, DIN 1.2312 10/20mm Thick Plastic Mould Steel Plates | Technique: | Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw |
|---|---|---|---|
| Surface Treatment: | Black Or Machined, Black Bright Mirror(mill Polishing HL Etc), Black Surface Or Mi | Standard: | AISI, DIN, ASTM, GB, JIS |
| Application: | Mold Steel, Tool Stee, Die Steel, Special Steel | Shape: | Lat Bar/round Bar, Plate/sheet/ Flat Bar, Ba |
| Delivery Condition: | Raw, According To The Demand Of The Customer Inquire, Standard Seaworthy Package | ||
| High Light: | Din 1.2311 Plastic Mold Steel,Din 1.2311 Steel Round Bar,3Cr2Mo Steel Round Bar |
||
Steel Round Bar Din 1.2311 ／ Plastic Mould Steel For Plastic Mold
Description
Plastic mold includes thermoplastic mold and thermosetting plastic mold. The steel for plastic mould is required to have certain properties such as strength, hardness, wear resistance, thermal stability and corrosion resistance.
Specification
| Product Name |
alloy steel/carbon steel/steel round bar |
| Length | custom-made |
| Width | custom-made |
| Thickness | any size can custom-made |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled/forged/cold draw |
| Surface Treatment | clean/black rough/milled/grinding painting etc. |
| Thickness tolerance | ±0.15mm |
| MOQ | 1 ton to 25 tons and accept sample order |
| Shipping time | 15-20 days after receiving deposit or L/C |
| Export packing | Standrad export seaworthy package/ wooden box package |
| Capacity | 12000 tons/year |
Material
3Cr2Mo/1.2311/1.2312/P20/1.2738/718H/P20+Ni/1.2316/1.2083/4Cr13
/sus420j2/420/S136/NAK80H13/1.2344/SKD61/5CrNiMo/SKT4/1.2714
Cr12/D3/1.2080/Cr12MoV/D2/1.2379/SKD11/9CrWMn/O1/1.2510/SKS3 /DC53
40Cr/5140/35CrMo/42CrMo/4140/1.7225
C45/C50/1045/1050/S50C/S45C/T10/T8
M2/1.338/SKH51
CUSTOM-MADE
Chemical composition
| Grade | C | Si | Mn | Cr | Mo | P | S | ||
| DIN | 1.2311 | 0.35~0.45 | 0.20~0.40 | 1.30~1.60 | 1.80~2.10 | 0.15~0.25 | ≤0.03 | ≤0.03 | |
| AISI | P20 | 0.28~0.4 | 0.2~0.8 | 0.6~1.0 | 1.4~2.0 | 0.3~0.55 | ≤0.03 | ≤0.03 | |
