9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel

9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel
9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel

Large Image :  9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel

Product Details:
Place of Origin: CHINA
Brand Name: takford
Model Number: 440C/9CR18MO
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: usd 3-5/kg
Packaging Details: SEA SAFETY PACKAGE
Delivery Time: 10-20 DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 tons per month

9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel

Description
Technique: Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw Application: Plastic Mold Steel, Rust Protection Mold Steel
Special Use: Wear Resistant Steel, High-strength Steel Plate, Mould Steel, Hot Work Tool Steel , Alloy Steel Delivery Condition: Hot Forged +Rough Machined (black Surface, N+T, T, Without Packed, OT
Packing: Raw, According To The Demand Of The Customer Inquire, Standard Seaworthy Package Shape: Plate And Round Bar
Standard: AISI, DIN, ASTM, GB, JIS
High Light:

9Cr18Mo Plastic Mold Steel

,

AISI 440C Plastic Mold Steel

,

9Cr18Mo Tool Steel

9Cr18Mo,AISI 440C, Wear Resistance and Corrosion Resistance Plastic mould steel



9Cr18Mo,AISI 440C, Wear Resistance and Corrosion Resistance Plastic mould steel



9Cr18Mo may be a martensitic chrome steel with high carbon and Cr. It bears high hardness, heat resistance, tempering resistance, corrosion resistance and wonderful dimensional stability at elevated temperature. it's appropriate for plastic moulds needed high load, nice wear resistance and sensible corrosion resistance.





Chemical Composition of 9Cr18Mo (%):





C



Si



Mn



Cr



Mo



0.95~1.10



≤0.80



≤0.80



16.00~18.00

0.40-0.70





Standard specification of 9Cr18Mo:



AISI 440C, JIS SUS440C.



Characteristics of 9Cr18Mo:



9Cr18Mo may be a high-chrome and Mo alloy wear resistance and corrosion resistance plastic mould steel with high hardness. The content of chrome within the steel reaches Sixteen Personality Factor Questionnaire or higher, superimposed with atomic number 42|metal} alloy element, so the steel has superior resistance to abrasion and corrosion. it's largely appropriate for electrical plastics, home appliances and plastic mould superimposed with flame retardation.



Delivery condition of 9Cr18Mo:



Annealed: ≤269HB



Specifications of 9Cr18Mo:



1. Size of flat bars: 10~130mm*200~410mm.

2. spherical bars: Φ10~Φ200mm.

3. Size of solid flat bars: 100~300mm.



Applications of 9Cr18Mo:



1. Electrical plastics and plastic mould superimposed with flame retardation.

2. appropriate for creating the molds for numerous medium or top-grade electrical switches, chargers and electrical kettle seat.

3. additionally used for creating the molds for plugs and inserts on laptop, camera and alternative preciseness instruments.

9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 09Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 1

9Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 29Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 39Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 49Cr18Mo AISI 440C Wear Resistance Plastic Mold Steel 5
