Product Details:
|
| Technique: | ESR Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw | Type: | Steel Plate |
|---|---|---|---|
| Application: | Injection Mold Base | Product Name: | High Carbon Steel S50CFor For Injection Mold Base With Milling Surface |
| Standard: | AISI, DIN, ASTM, GB, JIS | Thickness: | From 8mm Up To 500mm |
| Special Use: | Plastic Mold Base, Standard Mold Base | Package: | Wrap Plastic Film+wooden Pallet If +wooden Case-- Need To Charge |
| High Light: | C50 Carbon Steel Flat Bar,400mm S50C Carbon Steel,AISI1050 Carbon Steel Flat Bar |
||
S50C/C50/AISI1050 Carbon Steel flat bar with milled surface thickness from 8mm up to 400mm
C50 Carbon steel is high strength steel,C50 carbon steel plate has cold plastic deformation ,welding performance and low hardenability,C50 steel 's yield strength is between 320-610 MPa ,C50 steel plate tensile strength is from290MPa to 590MPa. C50 Carbon steel plate has excellent mechanical properties and widely application.BBN Steel is specializing in C50 steel which is under EN 10083 specification.
C50 steel plate is mainly composed of medium carbon elements and other minor alloying elements.More detailed information, please refer to the flowing table:
| Chemical elements | C | Si max. |
Mn | P max. |
S max. |
Cr max. |
Mo max. |
Ni max. |
Cr+Mo+Ni max. |
| %, by mass | 0,47-0,55 | 0,40 | 0,60-0,90 | 0,045 | 0,045 | 0,40 | 0,10 | 0,40 | 0,63 - - |
| Permissible deviation | ± 0,02 | + 0,03 | ± 0,04 | + 0,005 | + 0,005 | + 0,05 | + 0,03 | + 0,05 |
