Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel

Certification
China DONGGUAN MISUNG MOULD STEEL CO.,LTD certification
Customer Reviews
We are almost finish with the assembly of the Tool, the dimensions and workmanship is very good, we are impressed by your standards. We have to do some testing of tool to give complete feedback but so far we happy with your quality, thank you and have a nice day.

—— Will Smith

I am very happy with your products, you are the best suppliers for us.

—— JAHANZAIB

We work with takford for more than 6 years, takford is the trusted suppliers.

—— Shahin shahi Pasand

I'm Online Chat Now

Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel

Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel
Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel
Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel

Large Image :  Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel

Product Details:
Place of Origin: CHINA
Brand Name: takford
Model Number: P20/1.2311/3CR2MO
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: usd 0.8-1.5/kg
Packaging Details: According to The Demand of The Customer Inquire, Standard Seaworthy Package
Delivery Time: 5-10 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 tons per month

Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel

Description
Product Name: 1.2311 Mold Steel Plate Manufacotry Plastic Mold Base Thermoplastic Mold Technique: Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw
Surface Treatment: Milled And Grinding Standard: AISI, DIN, ASTM, GB, JIS
Application: Mould Base Of TV Front Shell, Telephone Set, Drinking Machine, Vacuum Cleaner Shape: Plate, Sheet, Steel Plate/flat Bar/round Bar, Plate/sheet/ Flat Bar, Ba
Delivery Condition: Raw, According To The Demand Of The Customer Inquire, Standard Seaworthy Package
High Light:

1.2311 Thermosetting Mold Steel

,

1.2311 Plastic Mold Steel

,

Plastic Mold Steel

1.2311 Mold Steel Plate manufacotry plastic mold base thermoplastic mold



Description



Plastic mold includes thermoplastic mold and thermosetting plastic mold. The steel for plastic mould is required to have certain properties such as strength, hardness, wear resistance, thermal stability and corrosion resistance.



Application:



It is suitable for plastic mould and mould base of TV front shell, telephone set, drinking machine, vacuum cleaner, etc.

Thermoplastic injection mold, extrusion mold.

Thermoplastic blow molding mold.

Heavy duty mold main parts.

Cold structural parts.

Commonly used in the manufacture of television case, washing machine, refrigerator inner shell, bucket, etc



Specification



Product Name

alloy steel/carbon steel/steel round bar

Length custom-made
Width custom-made
Thickness any size can custom-made
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled/forged/cold draw
Surface Treatment clean/black rough/milled/grinding painting etc.
Thickness tolerance ±0.15mm
MOQ 1 ton to 25 tons and accept sample order
Shipping time 15-20 days after receiving deposit or L/C
Export packing Standrad export seaworthy package/ wooden box package
Capacity 12000 tons/year



Material



3Cr2Mo/1.2311/1.2312/P20/1.2738/718H/P20+Ni/1.2316/1.2083/4Cr13

/sus420j2/420/S136/NAK80H13/1.2344/SKD61/5CrNiMo/SKT4/1.2714

Cr12/D3/1.2080/Cr12MoV/D2/1.2379/SKD11/9CrWMn/O1/1.2510/SKS3 /DC53

40Cr/5140/35CrMo/42CrMo/4140/1.7225

C45/C50/1045/1050/S50C/S45C/T10/T8

M2/1.338/SKH51

CUSTOM-MADE





Chemical composition



  Grade C Si Mn Cr Mo P S
DIN 1.2311 0.35~0.45 0.20~0.40 1.30~1.60 1.80~2.10 0.15~0.25 ≤0.03 ≤0.03
AISI P20 0.28~0.4 0.2~0.8 0.6~1.0 1.4~2.0 0.3~0.55 ≤0.03 ≤0.03





Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel 0Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel 1

Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel 2Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel 3Corrosion Resistance 1.2311 Thermosetting Plastic Mold Steel 4
