100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel

100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel
100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel 100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel 100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel 100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel

Large Image :  100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel

Product Details:
Place of Origin: China
Brand Name: TAKFORD
Model Number: D2/1.2379/SKD11/CR12MOV
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 2-4 USD/KG
Packaging Details: SEA SAFE PACAKGE
Delivery Time: 5-8 WORKING DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 TONS PER MONTH

100mm Diamater Round Bar 1.2379 / AISI D2 Tool Steel

Description
Steel Grade: D2/1.2379/SKD11/CR12MOV Technique: ESR Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw
Alloy Or Not: Is Alloy, Non-alloy Standard: AISI, DIN, ASTM, GB, JIS
Delivery Condition: Peeled, EAF+LF+VD, Finish Machining, Q+T, Annealed Or QT. Application: Tool Steel Bar, Die Steel Bar, Structural Steel Bar, Industry, Cold Work Tool Steel
Name: D2 Steel Round Bar For Cold Stamping Dies With High Wear Resistance And Long Life Dimensions: Dia 6mm-430mm , Plate Thickness 6-400mm
High Light:

100mm AISI D2 Tool Steel

,

AISI D2 Tool Steel

,

100mm 1.2379 D2 Steel Bar

GOOD CORROSION RESISTANCE 1.2379 / D2 STEEL ROUND BAR 100MM DIAMATER



Description

D2/1.2379/ die steel is a kind of high carbon and high chromium cold working die steel widely used in the world. It belongs to ledeburite steel with high hardenability, hardenability and high wear resistance. It has good high temperature oxidation resistance, good corrosion resistance after quenching and polishing, and small deformation after heat treatment



Application:



It is suitable for tool steel with complex deformation, various cold stamping dies with high wear resistance and long life, cold cutting edge, thread rolling plate, cold extrusion forming, drawing die, stainless steel sheet and blanking die for high hardness materials.



D2/1.2379/CR12MO1V1 /SKD11 Chemical composition:



C
Si
Mn
S
P
Cr
Ni
Cu
V
Mo
1.40-1.6
0.6
0.6
0.03
0.03
11.5-13
0.25
0.30
1.00
0.70



Detail information:



1) Used for drawing die of refrigerator compressor back cover, quenching hardness 56 ~ 58 HRC.

2) In order to improve the service life of D2 cold work die flat steel, the wear resistance and impact toughness of the steel are greatly improved by adding rare earth, so as to improve the service life of flat steel for round die.

3) Because the content of V and Mo in D2 steel is higher than that of Cr12MoV steel, D2 steel has better comprehensive properties, and the traditional Cr12MoV steel will be gradually replaced.

4) Compared with Cr12MoV steel, the service life of cold stamping die made of D2 steel for thread rolling wheel and off stage adjusting plate can be increased by 5 ~ 6 times.



Product Name

mould steel/plastic mould steel/ tool steel/alloy steel/carbon steel/steel round bar

/steel plate/special steel/die steel/mould base/cold work tool steel/hot work tool steel/

Length any size can custom-made
Width any size can custom-made
Thickness any size can custom-made
Chemical composition



  Grade C Si Cr Mn Mo V P S
DIN 1.2379 1.5-1.6 0.1-0.4 11.0-12.0 0.15-0.45 0.6-0.8 0.9~1.1 ≤0.03 ≤0.03
AISI D2 1.4-1.6 0.1-0.6 11.0-13.0 0.2-0.6 0.7-1.2 0.5~1.1 ≤0.03 ≤0.03
JIS SKD11 1.4-1.6 ≤0.4 11.0-13.0 ≤0.6 0.8-1.2 0.2~0.5 ≤0.03 ≤0.03
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled/forged/cold draw
Surface Treatment clean/black rough/milled/grinding painting etc.
Thickness tolerance ±0.15mm
Material

3Cr2Mo/1.2311/1.2312/P20/1.2738/718H/P20+Ni/1.2316/1.2083/4Cr13

/sus420j2/420/S136/NAK80H13/1.2344/SKD61/5CrNiMo/SKT4/1.2714

Cr12/D3/1.2080/Cr12MoV/D2/1.2379/SKD11/9CrWMn/O1/1.2510/SKS3 /DC53

40Cr/5140/35CrMo/42CrMo/4140/1.7225

C45/C50/1045/1050/S50C/S45C/T10/T8

M2/1.338/SKH51

CUSTOM-MADE

MOQ 1 ton to 25 tons and accept sample order
Shipping time 15-20 days after receiving deposit or L/C
Export packing Standrad export seaworthy package/ wooden box package
Capacity 12000 tons/year
