34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar

34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar
34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar

Large Image :  34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar

Product Details:
Place of Origin: CHINA
Brand Name: takford
Model Number: 34CrNiMo6 / 1.6582
Payment & Shipping Terms:
Minimum Order Quantity: 20 tons
Price: 1.5-3 USD PER KG
Packaging Details: SEA SAFETY PACKAGE
Delivery Time: 10-20 DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 tons per month

34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar

Description
Name: 34CrNiMo6 Steel / 1.6582 Alloy Structure Steel Bar For Machine Shaft Shape: Round Bar
Applciaiton: Machine Shaft , Industry Alloy Or Not: Alloy
Condiction: Q+T Annealing Production: Hot Rolled And Forged
High Light:

34CrNiMo6 Structural Steel Bar

,

1.6582 Alloy Structural Steel

,

1.6582 Structural Steel Bar



34CrNiMo6 Steel / 1.6582 Alloy Structure Steel bar for machine shaft



 34CrNiMo6  Specfication



For 34CrNiMo6 / 1.6582, we can supply the steel round bar, steel flat bar, steel sheet, plate and square block. Round bar can be sawn to your required length and size. Rectangular steel pieces can be sawn from flat bar or plate to your specific sizes. Ground tool steel bar can be supplied, providing a quality precision finished bar and precision Steel plate to tight tolerances.



Engineering Alloy steel 34CrNiMo6 Applications properties



34CrNiMo6 / 1.6582 Steel used in the manufacture of tools for good plasticity and high strength. Usually choose a big size and important part, such as heavy machinery axle shaft, turbine blades and the high load of transmission parts, fasteners, crank shaft, gear, as well as loading part of the motor construction and so on.



34CrNiMo6 Chemical composition and Equivalents steel grade properties
BS EN 10083 – 3:2006 34CrNiMo6
/1.6582
C Si Si P S Cr Mo Ni
0.30-0.38 0.40 Max 0.50-0.80 0.025 max 0.035 max 1.30-1.70 0.15-0.30 1.30-1.70
BS EN 10250-3:2000 C Si Mn P S Cr Mo Ni
0.30-0.38 0.40 Max 0.50-0.80 0.035 max 0.035 max 1.30-1.70 0.15-0.30 1.30-1.70
ASTM A29: 2004 4337 C Si Mn P S Cr Mo Ni
0.30-0.40 0.20-0.35 0.60-0.80 0.035 max 0.040 max 0.70-0.90 0.20-0.30 1.65-2.00



34CrNiMo6 Steel Mechanical Properties

Diameter(mm) < 16 16~ 40 40~100 100~160 160 ~250
Thickness t (mm) < 8 8~20 20~60 60~100 100~160
Tensile strength Rm (N/mm2) 1200 – 1400 1100 – 1300 1000 – 1200 900 – 1100 800 – 950
Elongation A (%) 9 min 10 Min 11 Min Min 12 13 Min
Reduction of area Z (%) 40Min 45 Min 50Min 55Min 55MIn
Toughness CVN (J) 35Min 45Min 45Min 45Min 45 Min
Yield strength Re (N/mm²) 1000 Min 900 Min 800 Min 700 Min 600 Min



34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 034CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 1

34CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 234CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 334CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 434CrNiMo6 Steel Shaft 1.6582 Alloy Structural Steel Bar 5
