Product Details:
|
| Steel Grade: | Alloy Steel 38crmoal | Technique: | Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw |
|---|---|---|---|
| Special Use: | Mould Industry, Tool Steel | Application: | Structural Steel Bar, Die Steel Bar, Tool Steel Bar, Industry, Construction |
| Quality Inspection: | Chemical Composition, UT, Physical Properties Etc., Microstructure, Chemical Test | Standard: | AISI, DIN, ASTM, GB, JIS |
| Dimensions: | From 20mm Diameter Up To 500mm | ||
| High Light: | 38crmoal Alloy Steel Round Bar,260HB Alloy Steel Round Bar,38crmoal High Strength Alloy Steel |
||
38CrMoAl is a high-grade nitriding steel. On the basis of ordinary carbon Bai plain steel, nitrogen atoms are infiltrated into the surface layer of the workpiece in a certain medium at a certain temperature, so as to obtain the characteristics of high wear resistance, high fatigue strength, high strength, corrosion resistance and high temperature resistance.
It is mainly used for nitriding parts with accurate size after heat treatment, or various nitriding parts with low impact load and high wear resistance, such as mould imitation, cylinder liner, gear, high pressure valve, boring bar, worm, grinder spindle, etc., but the parts with larger size should not be used.
1. 38CrMoAl steel chemical composition:
| Materail | Chemical Composition % | ||||||
| C | Si | Mn | S/P | AL | Cr | Mo | |
| 38CrMoAl | 0.35-0.42 | 0.20-0.45 | 0.30-0.60 | 0.030 max | 0.70-1.10 | 0.80-1.10 | 0.15-0.25 |
2. 38CrMoAl steel mechanical properties:
| Mechanical Properties | ||||
| Yield Strength (MPa) | Tensile Strength (MPa) | Elongation | Reduction of area | |
| 980 min | 830 min | 12% min | 50% min | |
–2.Hardness:160~260HB
–3.Length:4000~6000mm
–4.UT-SEP 1921C/C or Better
–5.Chmical Analyzed 38CrMoAl ( or 1.8509 )
–6.Fix Diameter ( Accept the tolerance -/+1.5mm)
–7.SGS or other third party inspection under buyer‘s arrangement
