High Polishing Injection P80 Mirror Plastic Mold Steel
Basic Properties
Place of Origin:
CHINA
Brand Name:
takford
Model Number:
P80
Trading Properties
Minimum Order Quantity:
1 pc
Price:
USD 2-4/KG
Payment Terms:
L/C, T/T, Western Union
Supply Ability:
1000 TONS PER MONTH
Product Summary
P80 PLASTIC MOLD STEEL, TOOL STEEL, DIE STEEL, SPECIAL STEEL P80 Mirror Plastic Mould Steel for plastic injection mold with high polishing Main Application For high precision mirror-polishing plastic mould or moulds of household appliance which requires high surface condition. Delivery Condition EF ...
Product Details
Highlight:
P80 Injection Mold Steel
,P80 Plastic Mold Steel
,Mirror Plastic Mold Steel
Standard:
GB, JIS
Application:
PLASTIC MOULD, MOLD INDUSTRY
Surface:
Black Or Polish, Black Surface/machined Surface/bright Surface, Polished, Machined, Black/machined
Hardness:
36-42hrc
Shape:
Plate, Sheet, Steel Plate/flat Bar/round Bar, Plate/sheet/ Flat Bar, Bar
Product Description
P80 PLASTIC MOLD STEEL, TOOL STEEL, DIE STEEL, SPECIAL STEEL
P80 Mirror Plastic Mould Steel for plastic injection mold with high polishing
Main Application
For high precision mirror-polishing plastic mould or moulds of household appliance which requires high surface condition.
Delivery Condition
EF or Esr, Hot rolled or Forged, black surface or milling
Hardness:37-43HRC
Width:205-610mm Thickness:20-250mm
Characteristics
Low alloy precipitated hardening steel; good comprehensive mechanical properties,high hardenability, convenient heat treatmernt, good polishability. Also has good nitriding, electrical machining. welding and pattern etching performance.
Chemical Analysis
| Foreign Grade | China Grade | C | Si | Mn | P | S | Cr | Mo | Ni | Others |
| --- | 10Ni3MnCuAl | 0.10-0.15 | 0.10-0.15 | 1.00-2.00 | ≤0.03 | ≤0.03 | ---- | 0.10-0.40 | 2.50-3.5 |
Cu 0.70-1.50 Al 0.70-1.10 |
| P80 | ---- | 0.15 | 0.30 | 1.50 | --- | ---- | 0.30 | 0.30 | 3.00 |
Cu 1.00 Al 1.00 |
