AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar

Certification
China DONGGUAN MISUNG MOULD STEEL CO.,LTD certification
Customer Reviews
We are almost finish with the assembly of the Tool, the dimensions and workmanship is very good, we are impressed by your standards. We have to do some testing of tool to give complete feedback but so far we happy with your quality, thank you and have a nice day.

—— Will Smith

I am very happy with your products, you are the best suppliers for us.

—— JAHANZAIB

We work with takford for more than 6 years, takford is the trusted suppliers.

—— Shahin shahi Pasand

I'm Online Chat Now

AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar

AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar
AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar

Large Image :  AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar

Product Details:
Place of Origin: CHINA
Brand Name: takford
Model Number: 1.2312 /P20+S
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: usd 0.8-1.5/kg
Packaging Details: According to The Demand of The Customer Inquire, Standard Seaworthy Package
Delivery Time: 5-10 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 tons per month

AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar

Description
Product Name: 1.2312 / P20+S Technique: Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw
Surface Treatment: Black Or Machined, Black Bright Mirror(mill Polishing HL Etc), Black Surface Or Mi Standard: AISI, DIN, ASTM, GB, JIS
Application: Mould Base Of TV Front Shell, Telephone Set, Drinking Machine, Vacuum Cleaner Shape: Plate, Sheet, Steel Plate/flat Bar/round Bar, Plate/sheet/ Flat Bar, Ba
Delivery Condition: Raw, According To The Demand Of The Customer Inquire, Standard Seaworthy Package
High Light:

P20+S Plastic Mold Steel

,

34HRC Plastic Mold Steel

,

28HRC Plastic Mold Steel

1.2312 Plastic mold steel

Description:



DIN 1.2312 steel is a high quality plastic mold steel material. Steel 1.2312 is material produced by add about 0.08% sulphur on material 1.2311. The S element improves free cutting ability of 1.2311 steel . 2312 material is usually delivered in pre-hardness condition and hardness 28~34HRC.

ASTM P20+S steel is equivalent to DIN 1.2312 material. Generally, 40CrMnMoS8-6/1.2312 and P20+S mold steel will have the same properties for final application.



2. Relevant DIN 1.2312 Steel Specification and Equivalent Steel Grades

Country German USA
Standard DIN EN ISO 4957  ASTM/AISI
Grades 1.2312 P20+S


3. DIN 1.2312 Material Chemical Composition and Equivalent
DIN ISO 4957 C Mn P S Si Cr Mo
1.2312 0.35 0.45 1.30 1.60 0.03 0.005-0.1 0.20 0.40 1.80 2.10 0.15 0.25
 ASTM A681 C Mn P S Si Cr T
P20+S 0.28 0.40 0.60 1.00 0.03 0.03 0.20 0.80 1.40 2.00 0.30 0.55



Specification

Product Name

alloy steel/carbon steel/steel round bar

Length custom-made
Width custom-made
Thickness any size can custom-made
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled/forged/cold draw
Surface Treatment clean/black rough/milled/grinding painting etc.
Thickness tolerance ±0.15mm
MOQ 1 ton to 25 tons and accept sample order
Shipping time 15-20 days after receiving deposit or L/C
Export packing Standrad export seaworthy package/ wooden box package
Capacity 12000 tons/year




AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar 0AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar 1
AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar 2AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar 3AISI ASTM P20+S 28-34HRC Plastic Mold Steel round bar 4
