Molybdenum Welding High Speed Tool Steel M2 1.3343 SKH51 Grade

Molybdenum Welding High Speed Tool Steel M2 1.3343 SKH51 Grade
Molybdenum Welding High Speed Tool Steel M2 1.3343 SKH51 Grade

Large Image :  Molybdenum Welding High Speed Tool Steel M2 1.3343 SKH51 Grade

Product Details:
Place of Origin: CHINA
Brand Name: takford
Model Number: M2/1.3343/SKH51
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: usd 8-15/kg
Packaging Details: SEA SAFETY PACKAGE
Delivery Time: 10-20 DAYS
Payment Terms: L/C, D/P, T/T
Supply Ability: 100 tons per month

Molybdenum Welding High Speed Tool Steel M2 1.3343 SKH51 Grade

Description
Type: Alloy Steel Bar, Carbon Steel Bar, Tool Steel, Mold Steel, Ally Steel Bar/Sheet Steel Grade: M2/1.3343/SKH51
Application: Blade And Mold Surface Treatment: Black Or Machined, Black Bright Mirror(mill Polishing HL Etc), Black Surface Or Mi
Tolerance: K11 Or H9, H9&h11, 0/+1.0mm(turned) -0/+5.0mm(black) Standard: DIN, ASTM, AISI, GB, JIS
Hardness: Annealing Or 50-65 HRC
High Light:

SKH51 High Speed Tool Steel

,

molybdenum High Speed Tool Steel

,

M2 welding high speed steel

SKH51 High Speed Steel flat bar Quenched and tempered in 65HRC



M2 is a molybdenum type high speed steel, which has the advantages of low carbide inhomogeneity and high toughness.It is easy to overheat, so the quenching temperature should be strictly controlled.Due to its good hardness and wear resistance, it is mainly used to make cutting tools of difficult cutting materials.M2 high speed steel has a great tendency of carbide, so it has a strict requirement for heat treatment protection, and is suitable for dies bearing vibration and impact load.



Application:

Cold forging die, precision punching die, powder pressing die, shearing machine die, plastic die with glass fiber added, etc.Suitable for bearing shock and impact load: deep drawing die, punching die.Metal cutting blades, cold heading and extrusion tools, etc.



Product Name

mould steel/plastic mould steel/ tool steel/alloy steel/carbon steel/steel round bar

/steel plate/special steel/die steel/mould base/cold work tool steel/hot work tool steel/

Length any size can custom-made
Width any size can custom-made
Thickness any size can custom-made
Chemical composition
Grade C Si W Cr Mn Mo V P S
M2 0.80-0.90 0.20-0.45 5.5-6.75 3.8-4.4 0.15-0.40 4.5-5.5 1.75-2.2 ≤0.03 ≤0.03



Grade C Si W Cr Mn Mo V P S
SKH51 0.85 0.45 5.80 4.0 0.45 4.8 1.8 0.03 0.01
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled/forged/cold draw
Surface Treatment clean/black rough/milled/grinding painting etc.
Thickness tolerance ±0.15mm
Material

3Cr2Mo/1.2311/1.2312/P20/1.2738/718H/P20+Ni/1.2316/1.2083/4Cr13

/sus420j2/420/S136/NAK80H13/1.2344/SKD61/5CrNiMo/SKT4/1.2714

Cr12/D3/1.2080/Cr12MoV/D2/1.2379/SKD11/9CrWMn/O1/1.2510/SKS3 /DC53

40Cr/5140/35CrMo/42CrMo/4140/1.7225

C45/C50/1045/1050/S50C/S45C/T10/T8

M2/1.338/SKH51

CUSTOM-MADE

MOQ 1 ton to 25 tons and accept sample order
Shipping time 15-20 days after receiving deposit or L/C
Export packing Standrad export seaworthy package/ wooden box package
Capacity 12000 tons/year
