Product Details:
|
| Steel Grade: | D2/1.2379/SKD11/CR12MOV | Technique: | ESR Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot Rolled/forged/cold Draw |
|---|---|---|---|
| Alloy Or Not: | Is Alloy, Non-alloy | Standard: | AISI, DIN, ASTM, GB, JIS |
| Delivery Condition: | Peeled, EAF+LF+VD, Finish Machining, Q+T, Annealed Or QT. | Application: | Tool Steel Bar, Die Steel Bar, Structural Steel Bar, Industry, Cold Work Tool Steel |
| Name: | D2 Steel Round Bar For Cold Stamping Dies With High Wear Resistance And Long Life | Dimensions: | Dia 6mm-430mm , Plate Thickness 6-400mm |
| High Light: | Turned Surface Forged Steel Round Bar,400mm Cold Work Tool Steel,SKD11 Forged Steel Round Bar |
||
JIS SKD11 Forged Steel Round Bar Turned Surface 400mm Diameter
Description
SKD11 die steel is a kind of high carbon and high chromium cold working die steel widely used in the world. It belongs to ledeburite steel with high hardenability, hardenability and high wear resistance. It has good high temperature oxidation resistance, good corrosion resistance after quenching and polishing, and small deformation after heat treatment
Cold working processes include rolling, stretching, spinning, hammering, etc. As the amount of cold working increases, the material becomes harder due to deformation of the crystal structure, a process known as work hardening.
Application:
It is suitable for tool steel with complex deformation, various cold stamping dies with high wear resistance and long life, cold cutting edge, thread rolling plate, cold extrusion forming, drawing die, stainless steel sheet and blanking die for high hardness materials.
SKD11 Chemical composition:
|
C
|
Si
|
Mn
|
S
|
P
|
Cr
|
Ni
|
Cu
|
V
|
Mo
|
|
1.40-1.6
|
0.6
|
0.6
|
0.03
|
0.03
|
11.5-13
|
0.25
|
0.30
|
1.00
|
0.70
|
Detail information:
1) It is used for the drawing die of the back cover of the refrigerator compressor, and the quenching hardness is 56-58 HRC.
2) In order to improve the service life of D2 cold working die flat steel, the wear resistance and impact toughness of steel are greatly improved by adding rare earth, thereby improving the service life of round die flat steel.
3) Since the content of V and Mo in D2 steel is higher than that of Cr12MoV steel, D2 steel has better comprehensive properties, and the traditional Cr12MoV steel will be gradually replaced.
4) Compared with Cr12MoV steel, the life of cold stamping die of D2 steel rolling wheel and lower regulating plate can be increased by 5 to 6 times.
| Product Name |
mould steel/plastic mould steel/ tool steel/alloy steel/carbon steel/steel round bar /steel plate/special steel/die steel/mould base/cold work tool steel/hot work tool steel/ |
||||||||||||||||||||||||||||||||||||||||
| Length | any size can custom-made | ||||||||||||||||||||||||||||||||||||||||
| Width | any size can custom-made | ||||||||||||||||||||||||||||||||||||||||
| Thickness | any size can custom-made | ||||||||||||||||||||||||||||||||||||||||
| Chemical composition |
|
||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. | ||||||||||||||||||||||||||||||||||||||||
| Technique | Hot rolled/forged/cold draw | ||||||||||||||||||||||||||||||||||||||||
| Surface Treatment | clean/black rough/milled/grinding painting etc. | ||||||||||||||||||||||||||||||||||||||||
| Thickness tolerance | ±0.15mm | ||||||||||||||||||||||||||||||||||||||||
| Material |
3Cr2Mo/1.2311/1.2312/P20/1.2738/718H/P20+Ni/1.2316/1.2083/4Cr13 /sus420j2/420/S136/NAK80H13/1.2344/SKD61/5CrNiMo/SKT4/1.2714 Cr12/D3/1.2080/Cr12MoV/D2/1.2379/SKD11/9CrWMn/O1/1.2510/SKS3 /DC53 40Cr/5140/35CrMo/42CrMo/4140/1.7225 C45/C50/1045/1050/S50C/S45C/T10/T8 M2/1.338/SKH51 CUSTOM-MADE |
||||||||||||||||||||||||||||||||||||||||
| MOQ | 1 ton to 25 tons and accept sample order | ||||||||||||||||||||||||||||||||||||||||
| Shipping time | 15-20 days after receiving deposit or L/C | ||||||||||||||||||||||||||||||||||||||||
| Export packing | Standrad export seaworthy package/ wooden box package | ||||||||||||||||||||||||||||||||||||||||
| Capacity | 12000 tons/year |
